🆕3 Inch 170W 6000K Hyperboloid Bi-LED Projector Lens Headlight with Round Spot Auxiliary High Beam K9 Series, Retrofit Cutting Installation for Car | 2PCS/Set
MAIN FEATURES
ULTRA-HIGH BRIGHTNESS, SUPERIOR VISIBILITY
- Equipped with 6+1+1 high-performance LED chips, providing a maximum illumination range of up to 1200 meters. 300% brighter than standard halogen headlights.
- 40W/each low beam, 85W/each high beam. Dual independent light sources deliver a powerful output of up to 21,000 lumens.
INDEPENDENT DUAL DIRECT-PROJECTION BEAM DESIGN
- Each headlight features two independent direct-projector lenses, producing a wider, sharper, and more uniform beam.
- Dual-reflector optical design optimises both high and low beam distribution for perfect road coverage.
- Minimizes scattered light and glare for oncoming drivers, improving safety for all road users under various driving conditions.
PERFECT BEAM PATTERN
- Low Beam: Features a clearly defined tangential cut-off and wide-angle illumination with a precise focal point. Delivers a sharp cut-off line and a uniform beam pattern free of blind zones or dark spots.
- High Beam: Offers an accurately focused, long-range spotlight with zero astigmatism. Projects a wide and evenly distributed beam pattern for enhanced road coverage.
- Auxiliary High Beam (Round Spotlight): Provides an intensely focused circular hotspot with extreme brightness and exceptional long-range penetration, ideal for high-speed or poorly lit environments.
CUSTOM RETROFIT INSTALLATION
- This projector lens requires modification of the headlight housing(such as cutting or trimming the reflector bowl) to fit properly.
- It is not a plug-and-play design. Professional installation by an experienced retrofit workshop is strongly recommended to ensure optimal lighting performance and safety.
- Critical Note: Installation involves permanent alteration of the original headlight assembly. Please confirm your willingness to modify your vehicle before purchase.
ADVANCED COOLING SYSTEM
- Dual copper heat pipes + turbo cooling fan actively control operating temperature, preventing light decay and extending product lifespan.
- Supports stable operation for up to 50,000 hours, offering significantly higher durability and reliability compared to traditional halogen or HID lights.
SPECIFICATIONS
Size: 3 Inch
LED Chips: 6+1+1pcs LED Chips
Power: Low Beam 40W/per, High Beam 85W/per
Operating Voltage:12V
LED Quantity(per bulb): 8PCS
Color Temperature: 6000K White
Luminous Flux: Low Beam 8840LUX, High Beam 21000LUX
Adapter Type: H4, H7, 9005, 9006
Material: Aluminum Alloy Body + High Clear Lens
Heat Dissipation Mode: Built-in Heat-Sink Fan
LED Lifetime：30,000 Hours
Operating Temperature: -40°C degree~120 °C degrees
PACKAGE INCLUDED
- 3 Inch Hyperboloid Bi-LED Projector Lens Headlight *2
